Design
Product colour: Black
Mounting type: Table/Ceiling
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 95%
Weight & dimensions
Width: 570 mm
Weight: 3.81 kg
Depth: 80 mm
Height: 65 mm
Performance
Auto framing: Yes
Tracking modes: Presenter mode
Firmware upgradeable: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n), 802.11b
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Bluetooth version: 5.1
Bluetooth: Yes
Wi-Fi: Yes
Cable lock slot: Yes
Auto-tracking: Yes
Packaging content: • MeetingBar A25
• Power adapter
• HDMI cable x1
• Network cable x1
• USB A to C cable x1
• Wall Mount x1
• USB C to C cable
• VCR11
Packaging content
Remote control included: Yes
AC adapter included: Yes
Mounting kit: Yes
Power supply included: Yes
Cables included: HDMI, LAN (RJ-45), USB
Audio
Microphone Total Harmonic Distortion (THD): 5%
Number of microphone arrays: 8
Supported sample rates: 32 kHz
Speaker frequency range: 100 - 16000 Hz
Microphone pick-up range: 5 m
Audio codecs: ARES, G.722.1C, G.722.1, G.722, G.711 (PCMA/PCMU), G.729
Sound pressure level (max): 110 dB
Built-in speaker(s): Yes
Built-in microphone: Yes
Microphone frequency response: 100 - 20000 Hz
Microphone sensitivity: -38 dB
Ports & interfaces
USB 2.0 Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Line-out: Yes
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Camera
Horizontal field of view (tele): 84.4°
Camera type: Triple camera
Privacy camera: Yes
Privacy type: Privacy cover
Horizontal field of view (wide): 151°
Vertical field of view (tele): 53.1°
Vertical field of view (wide): 81°
Video
HD type: 4K Ultra HD
Picture-in-Picture: Yes
Maximum frame rate: 30 fps
Video formats supported: H.264
Maximum video resolution: 3840 x 2160 pixels
