Technical details
Sustainability certificates: RoHS
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Weight: 161.6 g
Height: 165 mm
Depth: 99 mm
Width: 66 mm
Performance
LED indicators: Yes
Product colour: Black
International Protection (IP) code: IP42
Packaging data
Charging base: No
Cables included: Micro-USB
Ports & interfaces
Standard interfaces: USB, RS-232, RS-485, Keyboard wedge
Connectivity technology: Wired
Scanning
Linear (1D) barcodes supported: Code 128, Codabar, MSI, Code 39, Code 11, EAN-13, Code 93, U.P.C., Interleaved 2 of 5, GS1 DataBar Expanded
Type: Handheld bar code reader
2D (matrix & stacked) barcodes supported: Han Xin, Data Matrix, Micro QR Code, Aztec Code, QR Code, MaxiCode, TLC-39, Composite Codes, PDF417
Motion tolerance (cm/s): 13
Sensor type: LED
Pitch reading angle: -65 - 65°
Working distance: 36.8 cm
Tilt reading angle: -65 - 65°
Optical sensor resolution (W x H): 640 x 480 pixels
Wavelength: 645 nm
Scanner type: 1D/2D
Yaw reading angle: -65 - 65°
