Technical details
Compliance certificates: RoHS, CE, REACH, C-TICK, Federal Communications Commission (FCC), CCC, BSMI
Sustainability certificates: ENERGY STAR
Sustainability compliance: Yes
Design
Product colour: Black
Power
AC input frequency: 50 / 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 4.4 - 41 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 60 °C
Weight & dimensions
Height: 151 mm
Depth: 220 mm
Weight: 1 kg
Width: 115 mm
System requirements
Mobile operating systems supported: Android, iOS
Certification: IEC 60950-1, IEC 62368-1, EN55022 Class B, EN55024, EN55035, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus CE Marking, VCCI, C-Tick, S-Mark,
CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM
Performance
Scalable fonts: Swiss
Built-in barcodes: UPC-A, PLESSEY, MSI, EAN8, MaxiCode, Interleaved 2/5, Code 39, AZTECCODE, POSTNET, Code 128 (A/B/C), Code 93, QR Code, LOGMARS, Industrial 2/5, Code 49, EAN13, Data Matrix, Code 11, Codablock, CODABAR (NW-7), PDF417, UPC-E, MicroPDF417, Planet
Internal memory: 256 MB
Flash memory: 512 MB
Page description languages: EZPL
Packaging content
Cables included: AC, USB
Ports & interfaces
Optional connectivity: Serial (RS-232), Wireless LAN
Bluetooth Low Energy (BLE): Yes
USB port: Yes
Ethernet LAN: Yes
Connectivity technology: Wired & Wireless
Bluetooth: Yes
Printing
Colour: No
Maximum printing width: 5.4 cm
Maximum resolution: 300 x 300 DPI
Print technology: Direct thermal
Print speed: 102 mm/sec
Paper handling
Ribbon length: 74 m
Maximum roll diameter: 12.7 cm
Maximum label length: 0.991 m
Ribbon width: 5.8 cm
Core diameter: 1.27 cm
Media thickness: 0.06 - 0.1905 mm
Supported paper width: 15 - 57 mm
