Technical details
Compliance certificates: CE, REACH
Certification: EMC, CE, FCC, EAC, BSMI, Class B
Design
Component for: PC
Internal: Yes
LED indicators: Yes
Operational conditions
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 82 mm
Depth: 68 mm
Weight: 78 g
Height: 18 mm
Network
Ethernet LAN data rates: 100 Mbit/s, 1000, 10
Ethernet LAN: Yes
Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3bz, IEEE 802.3an, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3az
Ethernet interface type: Gigabit Ethernet
System requirements
Server operating systems supported: Windows Server 2012
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Packaging content
Quick installation guide: Yes
Mounting brackets included: Yes
Ports & interfaces
Interface: Ethernet
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Host interface: PCI Express
